Electric horizontal band saw, log splitting saw, frame, Lumag BSW76EPRO

1.574.016 HUF +VAT

BUDAPEST, 1151 Budapest (XV. kerület)

Sharing:

4





Description
The machine is equipped with a 400 volt motor as standard, but is also available with a powerful petrol engine (BSW76GL). Partly because of this, the machine can be set up wherever you want to saw wood. The standard length of the base is 5 metres, but it can be extended indefinitely. Thanks to the construction of the saw and the smooth, quiet running of the drive wheels, the saw is ideal for sawing soft, hard and dry wood. The saw is moved manually. The standard version is suitable for sawing logs up to 5 m long. As an option, the machine can be extended indefinitely with extra extensions (every 1950 mm). As a result, there is no limitation on the maximum machine length.

TECHNICAL DATA:

Main drive motor power: 5,5 kW S1 3/PE AC 400V-50Hz 16A IP54
Frame motor power: 0,18 kW, 400 V, 1330 rpm
Maximum log diameter: 760 mm
Maximum width of the log: 760 mm
Maximum saw blade height: 620 mm
Minimum saw blade height: 50 mm
Maximum depth of cut: 180 mm
Maximum cutting length of the basic version: 5 m
Minimum cutting length: 990 mm
Feeding of the saw unit: manual
Cutting height adjustment: electrically
Band saw wheel diameter: Ø 474 mm
Band saw wheel diameter: 24 mm
Saw blade dimensions: 4004 x 32 x 1,1 mm
Saw band speed (forward/reverse): 15 m/s
Saw blade thickness: 1,4 - 2,2 mm
Coolant tank capacity: 10 litres
Basic version dimensions (H x W x D): 6741 x 2075 x 2000 mm
Weight (net/gross): 400/453 kg
Packing dimensions (H x W x D): 2250 x 700 x 780 mm

The machine is equipped with motorised height adjustment with electric height indicator. The cutting thickness can be adjusted electronically and can also be set manually.

The machine is equipped with a Woodmaster / Lenox band saw (L/4004 x W/32 x H 1.1 mm, 22 mm tooth spacing), included!
